Fig 1502 High Pressure Low Torque Plug Valves 1" 2" 3" API 6A

API 6A 1" 2" 3" Fig 1502 High Pressure Low Torque Plug Valves

Flow line plug valve is a necessary part that is applied to high pressure manifold in well cementing and fracture services, also is selected for high pressure fluid control system. It is excellent for its compact structure, easy maintenance, low torque and rapid operation.

Feature:

* The plug valve consists of the valve body, plug cap, plug and etc.
* The plug valve is available with the union inlet and outlet connection and BOX and Pin thread connection.
* The metal-to-metal sealing is available between the side segments and cylinder plug, featuring high precision and reliability.
* Applied to standard, sour gas and low temperature service.

Specification:

Product Name	High pressure plug valve/low torque valve/flow line plug valve
Material Class	AA-EE
Working Media	Crude oil and natural gas
Processing Standard	API 6A
Working Pressure	3000~15000psi
Processing Type	Forge
Performance Requirement	PR1-2
Product specification level	PSL1-3
Nominal Bore Diameter	1", 2", 3"
Connection Type	Union, Thread

S/N	Model	Description	Rated	WP End connection
1	SF42-1"	1" plug valve	6000psi	2"male (LP)
2	SF70-1"	1" plug valve	10000psi	2"male (LP)
3	SF105-1"	1" plug valve	15000psi	2"male (LP)
4	SF105-1"	1" plug valve	15000psi	2"union (F*M)
5	SF42-2"	2" plug valve	6000psi	2" female (LP)
6	SF42-2"	2" plug valve	6000psi	2"union (F*M)
7	SF70-2"	2" plug valve	10000psi	2" female (LP)
8	SF105-2"	2" plug valve	15000psi	2"union (F*M)
9	SF42-3"	3" plug valve	6000psi	3"female (LP)
10	SF70-3	3" plug valve	10000psi	3"female (LP)
11	SF105-3	3" plug valve	15000psi	3"union (F*M)

Product Show:
